8 Port Rugged PoE Managed Switch 2.5G Fiber Uplinks 120W Budget DIN Mounted

8 Port Rugged PoE Managed Switch 2.5G Fiber Uplinks 120W Budget DIN Mounted

$139.99 USD
$154.99 USD $139.99 USD
Распродажа Продано
The IM-FP444GW is a managed industrial-grade PoE fiber switch designed for high-reliability Ethernet and fiber transmission in harsh environments.

1. It integrates 4 × 100/1000/2500Mbps SFP fiber ports with 4 × 10/100/1000Mbps PoE-enabled RJ45 ports, providing a flexible access and aggregation solution for industrial networks, outdoor surveillance, and distributed fiber architectures.
2. Compliant with IEEE 802.3af/at, the switch delivers up to 30W per PoE port with a total power budget of 120W, ensuring stable power and data transmission to IP cameras, wireless APs, and edge devices.
3. With its IP40-rated metal enclosure, DIN-rail or wall mounting, and wide operating temperature range of -40°C to +75°C, the IM-FP444GW is built for continuous operation in demanding industrial and outdoor deployments.



Key Features

The IM-FP444GW combines advanced Layer 2 management, industrial protection, and high-performance switching capabilities:

  1. Hybrid Fiber & PoE Design – 4 × 2.5G SFP ports for long-distance fiber transmission and 4 × Gigabit RJ45 PoE ports.
  2. Industrial PoE Power Delivery – IEEE 802.3af/at compliant, 30W per port, 120W total PoE budget, 48V output.
  3. Advanced Layer 2 Management – Supports VLAN (802.1Q), QoS, IGMP/MLD snooping, LACP link aggregation, and bandwidth control.
  4. Ring Protection & Redundancy – Supports STP, RSTP, MSTP, and ITU-T G.8032 Ethernet Protection Ring (EPR) for fast network recovery.
  5. Industrial Reliability – 6KV Ethernet surge protection, ESD protection up to ±15KV air, EMC industrial-grade compliance.
  6. High Switching Performance – 28Gbps switching capacity, 20.83Mpps forwarding rate, 8K MAC table, 9.6KB jumbo frames.
  7. Flexible Management – Web GUI, Cisco®-like CLI, SNMP v1/v2c/v3, Telnet, SSH, HTTPS, and firmware redundancy.
  8. Energy Efficient & Diagnostic Features – IEEE 802.3az EEE, cable diagnostics, port mirroring, RMON, and event logging.

Applications

  1. CCTV & Video Surveillance Systems – Ideal for powering IP cameras and PTZ devices while using fiber uplinks for long-distance backhaul.
  2. Industrial Automation Networks – Reliable connectivity for PLCs, industrial controllers, and distributed field devices.
  3. Smart Transportation & ITS – Supports roadside cameras, traffic monitoring systems, and railway communication networks.
  4. Energy  & Utility Networks – Suitable for substations, renewable energy sites, and power distribution monitoring systems.
  5. Campus & Industrial Parks – Acts as an access or aggregation switch connecting buildings, production zones, and outdoor facilities via fiber.
  6. Harsh Outdoor Environments – Designed for extreme temperatures, electrical noise, and surge-prone installations.
